What conditions require timely oil drains and service
L. (Tex) LeugnerLubrication Machine Building Metals equipment lubrication machine maintenance oil oil drains oil service water contamination
Oils do not wear out. Meaning, the base oil does not generally deteriorate; however, oil gradually loses its ability to carry out its functions of lubricating, reducing friction, and heat dissipation.
The gradual loss of lubrication quality is caused by self-generated oxidation due to overheating, viscosity changes caused by fuel dilution, or the shearing of viscosity improvers, water entry into the system, directly or through condensation and the gradual depletion of the additives as they counteract acids, disperse and suspend foreign materials.
There are other conditions that contribute to oil degradation to a lesser degree, among them poor quality fuel, equipment operation in over-cooled conditions, lean air/fuel ratios, and emission control systems that are malfunctioning, or have been removed or disconnected. Conditions that contribute to oil degradation and necessitate regular oil drains are described below.
Does your staff understand that oil degradation is self-generated?
Logic: every engine, hydraulic system, gear drive, gas turbine or other machine slowly wears as it operates. Tiny, sub-micronic particles, of such elements as iron and copper, become catalysts that slowly attack the oil. These tiny metallic contaminants, (that are the result of wear not the cause of it), combine with carbon soot and varnish particles resulting from normal lubrication processes circulate in the system and through chemical action, create more wear. These solid particles act as a fine grinding compound and will slowly scratch and score roller and journal bearing surfaces, crankshaft journals, cylinder liners, gear sets and hydraulic components.
Normal full‑flow filters are rated at about 10 micrometers in turbine and hydraulic systems, and 40 micrometres in engines, and will not remove these sub‑micronic particles. Furthermore, if these filters become plugged, or if the by‑pass valves within them remain open for long periods of time, such as at cold start up, contaminated oil will be pumped throughout the system. It is important to remember that if the levels of self‑generated contamination are allowed to increase until some damage by abrasion is caused, it will be too late to prevent more ongoing damage, even if the dirty oil is drained.
Can your maintenance group recognize the symptoms of oil oxidation?
Logic: oxidation is defined as a chemical deterioration of oil caused by continued contact with oxygen and catalysts such as copper. Oxidation causes the oil to thicken or increase in viscosity and darken in colour, sometimes dramatically, causing acids to form. This results in reduced oil flow and reduced heat dissipation that in turn accelerates the
Any practice that increases the operating temperatures of critical plant machinery must be avoided. Oil sump temperatures in diesel engines operating at high speed, and under heavy loads, can reach or exceed 150oC (302oF) with piston ring temperatures exceeding 310oC (590oF). Turbochargers may operate at up to 100,000 RPM with oil temperatures exceeding 315oC (600oF). If turbocharged engines are shut down immediately after operating at these temperatures, oxidation degradation of the oil can take place very quickly resulting in varnish formation.
Inoperative emission controls, thermostats with too high opening temperatures, etc, will increase the thermal load on gasoline engines, in turn increasing the rate of oxidation. Improperly adjusted air/fuel ratios contribute to oxidative oil thickening, because blow-by gases are produced containing high concentrations of nitrogen dioxide compounds that rapidly promote oil thickening.
Hydraulic systems operate best when the bulk oil in the reservoir does not exceed 60oC (140°F). Oxidation rates within hydraulic and turbine oils will approximately double for every 10oC (18°F) increase in temperature, causing sludge and varnish deposits and acid build-up causing corrosion. Oil temperatures in enclosed gear drives provide best service between 55 – 65 degrees C. Turbine bearing pad temperatures should not exceed 108°C.
Does the maintenance group understand the problems caused by water contamination?
Logic: any water entry into hydraulic or turbine systems can cause severe damage, particularly in systems with very close tolerances such as hydrostatic piston pump systems. Water contamination caused by condensation is a common problem in North American climates due to dramatic changes in temperatures. Hydraulic or turbine oil with a “milky” appearance is an indication of water in excess of 2,000 parts per million (PPM), and action must be taken to replace the oil or remove the water through special filtration systems available for this purpose.
Any water entry into hydraulic or turbine systems can cause severe damage, particularly in systems with very close tolerances such as hydrostatic piston pump systems.
In gasoline engines, the combustion of one gallon of gasoline produces about one gallon of water, and any moisture entering the crankcase through “blow-by” can cause rusting, corrosion, sludge deposits, and separation of additives from the base oil. Water entering the oil in a diesel engine can be extremely harmful, particularly if poor quality fuel is used. Poor quality fuel is generally high in sulphur content, and when water combines with sulphur dioxide, acids are formed that will immediately attack bearing surfaces. Water content in gear drives in excess of 400 – 500 ppm can reduce rolling element bearing fatigue life by up to 50 per cent.
Can the maintenance group recognize symptoms of poor fuel use?
Logic: the use of poor quality diesel fuel can cause severe corrosion problems, due to the formation of acids resulting from high sulphur content. If, however, it is necessary to use fuels with more than 15 ppm (0.0015 per cent) sulphur content, lubricating oil with a minimum API service rating of FA- 4 should be used. These oils are better able to counteract acids than oils of lesser quality.
Today, a more serious problem is premature wear of fuel system components due to the poor lubricity of diesel fuel, as a result of the removal of sulphur, which is a natural lubricant. Proper engine maintenance, such as correct and timely servicing of diesel particulate filters (DPFs) is critical. Ensure that water jacket temperatures are maintained above 79.5oC (175oF). Never operate an engine with the wrong thermostat, and excessive idling of diesel engines must be avoided. Unleaded gasoline is recommended for all gasoline engines, not only to reduce emissions, but to reduce the formation of lead compounds that form deposits, and contribute to self‑generating contaminant wear within the engine.
Does the maintenance group recognize the indications of additive depletion in oil?
Logic: when base oils are formulated and blended with additives, these chemical elements are slowly “used up” in performing their functions. Anti‑wear and extreme pressure agents are depleted as they are deposited on metal surfaces. Detergents and dispersant are used up as they continue to counteract and suspend contaminant particles in the oil.
Additives that protect against acid attacks are depleted as they counteract acid formations within the oil. The additive package will eventually become depleted or ineffective, if the oil is allowed to remain in service for extended periods. It is important to know that spectrometric oil analysis will continue to record additive chemicals on oil analysis reports even if these additives are no longer effective.
The only sure method of monitoring additive depletion is to establish a regularly, scheduled oil analysis program that not only monitors the rates of component wear, but also monitors total base or total acid number as applicable to diesel engine oil and industrial lubricants respectively, to determine a cost-effective oil drain and service schedule. MRO
L. (Tex) Leugner, the author of Practical Handbook of Machinery Lubrication, is a 15-year veteran of the Royal Canadian Electrical Mechanical Engineers, where he served as a technical specialist. He was the founder and operations manager of Maintenance Technology International Inc. for 30 years. Tex holds an STLE lubricant specialist certification and is a millwright and heavy-duty mechanic. He can be reached at firstname.lastname@example.org.
